600kg / 1000kg / 1500kg AGV AMR Chassis Platform Build Your Own Mobile Robotics

600 kg Differential Drive AMR Chassis
- Dimensions: approx. 950*620*200 mm
- Net Weight: 130 kg
- Payload Capacity: 600 kg

1000 kg Differential Drive AMR Chassis
- Dimensions: approx. 1150 * 820 * 260 mm
- Net Weight: 180 kg
- Payload Capacity: 1000 kg

1500 kg Differential Drive AMR Chassis
- Dimensions: approx. 1150 * 820 * 260 mm
- Net Weight: 200 kg
- Payload Capacity: 1500 kg

Other Features
- Lifting Stroke: 60 mm
- Performance: 1.5 m/s max speed at full load; acceleration 0.3 m/s²
- Control: Drive modules support ROS nodes and can be integrated with various upper-level controllers.
- Navigation Options: Customizable with different sensor solutions (e.g., QR code, camera, SLM LiDAR, etc.) based on application needs.
- Compliance: Configurable with safety-critical components to meet various safety standards, ensuring cost optimization.
