Connection Principle 1C

Model: 1C系列

Category: Key Components

Exhibitor:

EM-TECHNIK EAST ASIA LTD.

Booth No: J330

0
Share :
Share :

Description
1. Unique seamless design, completely leakproof. Chemical resistant, high-temperature-resistant, and stable for long-term use.
2. Hexagonal plate type is manufactured according to German DIN specifications.
3. PTFE material sealing ring is completely resistant to any chemical substances
4. PA, PP, PVDF, PFA are all available, chemical resistant.
5. Thread gauges are manufactured according to DIN, USAS, and JIS specifications.
6. Built-in expansion sleeves (connecting sleeves), chemical resistant, high-temperature-resistant, and stable for long-term use.
7. PEEK material cutting ring, with the best tensile resistance. Specially used for bridging hard pipes and smooth hard pipes, its built-in sleeves (connecting sleeves) have a special function, which will form a friction lock on the inserted pipe and completely prevent leakage, but can be removed at any time.
In addition, the unique PTFE sealing ring forms a complete seal and guarantees no leakage, locking the pipe without leakage, and the PEEK cutting ring locks the hard pipe or plastic hard pipe. It will not fall off. Finally, it is locked by the ribbed nut. The tighter the ribbed nut is locked, the tighter the PEEK cutting ring will lock the pipe.
