Large area vacuum gripping system

The ATS/ATV130 vacuum gripper is suitable for capturing products with different industry characteristics and can handle a variety of product specifications. It offers the flexibility to choose between standard suction cups or custom-designed suction cups based on actual application conditions, and different-sized suction cups can be freely combined and used in coordination.
The option to include a self-closing valve technology addresses challenges such as significant vacuum leakage, uneven surfaces, and irregularly shaped workpieces.
The vacuum source can be either internal or externally connected, providing options for users.
When using the internal plug-in vacuum generator, there is lower air consumption, higher vacuum flow, and shorter vacuum creation time.
For specific applications, the vacuum source can be externally connected, making it ideal for pairing with electrically driven vacuum generators such as blowers or vacuum pumps.
The integrated plug-in vacuum generation device allows for individual configuration and quick disassembly based on changes in working conditions.
Its modular design makes maintenance easy. Additionally, reserved interfaces allow for the direct attachment of functional components to the suction cup, optimizing processes and promoting environmental conservation and energy efficiency.
The main body of the suction cup is made from aluminum alloy, engineering plastic, and carbon fiber composite, providing high strength and lightweight characteristics.
The suction cup installation is simple, with a built-in T-shaped movable mounting slider that allows for fixing the suction cup and installing sensors or other components.
Rubber seal pad accessories can be quickly replaced when needed.

---
