Description
Magnetic Encoder Features
- Very small and durable design
- Customer-selectable resolution
- Including index sensor
- Status LED
Magnetic Encoder Specifications
- Only 8 mm high, 12 mm wide, 30 mm long
- RS422 A/B/Z incremental output
- Standard resolution: 1 μm
- Travel speed 6 m/s @ 1 μm resolution, 20 m/s @ 5 μm resolution
Operates at 5 VDC ± 10 %
- Very small and durable design
- Customer-selectable resolution
- Including index sensor
- Status LED
Magnetic Encoder Specifications
- Only 8 mm high, 12 mm wide, 30 mm long
- RS422 A/B/Z incremental output
- Standard resolution: 1 μm
- Travel speed 6 m/s @ 1 μm resolution, 20 m/s @ 5 μm resolution
Operates at 5 VDC ± 10 %
