Description
he warning signs, burning smells, unusual vibrations, or misalignment noises. By the time these symptoms show up, it’s usually too late. The truth is, breakdowns don’t happen suddenly—they build up over time.
This compact, industrial-grade condition monitoring sensor continuously tracks vibration, shock, and temperature, giving you early insight into potential problems before they become failures.
* 82% of system failures are due to improper installation, overload, or operational errors.
* The CMSVT38 gives you the data to detect, analyze, and prevent issues, keeping your equipment reliable and your team productive.
Whether integrated into your existing system or used as a standalone tool, this solution is built for harsh environments and ready to deliver real results.
-boosting uptime and protecting your assets.
* Vibration – Catch early signs of imbalance
* Shock – Detect mechanical impacts
* Temperature – Prevent overheating
Precise vibration measurement in three axes
Various setting options depending on the application requirements
Effective vibration speed (acceleration)
Peak-to-peak values
Simple commissioning, parameterization and installation
Visualization of operating states via LEDs.
LEDs in a translucent housing without bridging. This provides additional added value for the protection class.
Simple setting and adaptation of parameters and limit values to a wide range of application requirements (according to ISO 10816-3) via IO-Link.
Industry 4.0 ready with IO-Link interface
IO-Link interface for seamless integration and communication in the latest Industry 4.0 / IIoT control concepts.
Visual status display made easy
The sensor can be used in SIO mode with two PNP/NPN switching outputs, which are individually parameterized to the respective requirements via IO-Link. Limit values can then be visualized via suitable signal lights.
Precise measurement even under harsh environmental conditions
Temperature range -40 °C... +85 °C and protection class IP68 / IP69K
Robust housing with shock resistance up to 200 g
more...https://pse.is/7s3sfl
This compact, industrial-grade condition monitoring sensor continuously tracks vibration, shock, and temperature, giving you early insight into potential problems before they become failures.
* 82% of system failures are due to improper installation, overload, or operational errors.
* The CMSVT38 gives you the data to detect, analyze, and prevent issues, keeping your equipment reliable and your team productive.
Whether integrated into your existing system or used as a standalone tool, this solution is built for harsh environments and ready to deliver real results.
-boosting uptime and protecting your assets.
* Vibration – Catch early signs of imbalance
* Shock – Detect mechanical impacts
* Temperature – Prevent overheating
Precise vibration measurement in three axes
Various setting options depending on the application requirements
Effective vibration speed (acceleration)
Peak-to-peak values
Simple commissioning, parameterization and installation
Visualization of operating states via LEDs.
LEDs in a translucent housing without bridging. This provides additional added value for the protection class.
Simple setting and adaptation of parameters and limit values to a wide range of application requirements (according to ISO 10816-3) via IO-Link.
Industry 4.0 ready with IO-Link interface
IO-Link interface for seamless integration and communication in the latest Industry 4.0 / IIoT control concepts.
Visual status display made easy
The sensor can be used in SIO mode with two PNP/NPN switching outputs, which are individually parameterized to the respective requirements via IO-Link. Limit values can then be visualized via suitable signal lights.
Precise measurement even under harsh environmental conditions
Temperature range -40 °C... +85 °C and protection class IP68 / IP69K
Robust housing with shock resistance up to 200 g
more...https://pse.is/7s3sfl
