Description
Max Hose Size 2"
Crimping Range ( mm ) ψ4…ψ87
Die Type 32
Max. Opening ( mm ) +32
Master Die ( Die / Length ) 80
Motor ( kw ) 3.6
Voltage ( v ) 220 / 440
Pump ( l/min ) 11.5
Crimping Force ( kN ) 2200
Crimping Hour 1200
Noise level ( dB(A) ) 71
Protection Class IP54
Size : Length ( mm ) 680
Width ( mm ) 600
Height ( mm ) 1400
Weight ( kg ) 270
Crimping Range ( mm ) ψ4…ψ87
Die Type 32
Max. Opening ( mm ) +32
Master Die ( Die / Length ) 80
Motor ( kw ) 3.6
Voltage ( v ) 220 / 440
Pump ( l/min ) 11.5
Crimping Force ( kN ) 2200
Crimping Hour 1200
Noise level ( dB(A) ) 71
Protection Class IP54
Size : Length ( mm ) 680
Width ( mm ) 600
Height ( mm ) 1400
Weight ( kg ) 270
